| Item / Model | X(S)M-5E | X(S)M-10E | X(S)M-45E | X(S)M-90E | X(S)M-110E | X(S)M-135E | X(S)M-160E | X(S)M-190E | X(S)M-270E |
|---|---|---|---|---|---|---|---|---|---|
| Total Volume of Internal Mixer (L) | 5 | 10 | 45 | 87 | 110 | 139 | 160 | 195 | 250 |
| Filling Coefficient | 0.65 | 0.65 | 0.65 | 0.65 | 0.65 | 0.65 | 0.65 | 0.65 | 0.65 |
| Rotor Speed (r/min) | 6-60 | 6-60 | 6-60 | 6-60 | 6-60 | 6-60 | 5-50 | 6-60 | 4-40 |
| Maximum Ram Pressure (MPa) | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 |
| Main Motor Power (KW) | 45 | 75 | 280 | 520 | 630 | 750 | 750-800 | 1,250 | 1,250-1,500 |
| Overall Dimension – L | 2,225 | 3,700 | 5,500 | 7,000 | 7,500 | 8,500 | 8,600 | 5,950 | 7,450 |
| Overall Dimension – W | 2,125 | 1,800 | 2,300 | 2,800 | 3,000 | 3,100 | 4,800 | 3,400 | 4,140 |
| Overall Dimension – H | 1,100 | 3,000 | 3,600 | 4,150 | 4,500 | 5,000 | 5,730 | 5,600 | 6,270 |
| Total Equipment Weight (kg) | 5,000 | 6,500 | 9,500 | 23,000 | 28,000 | 31,500 | 36,000 | 45,000 | 59,000 |
| Item / Model | X(S)M-50 | X(S)M-80 | X(S)M-110 | X(S)M-160 | X(S)M-270 | X(S)M-430 |
|---|---|---|---|---|---|---|
| Total Volume of Internal Mixer (L) | 50 (Two-wing Rotor) | 80 (Four-wing Rotor) | 110 (Four-wing Rotor) | 160 (Two-wing Rotor) 147 (Four-wing Rotor) |
247 (Four-wing Rotor) | 425 (Four-wing Rotor) |
| Filling Coefficient | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 |
| Rotor Speed (r/min) | 4-40 (40) | 4-40 (40) | 4-40 (40) | 4-40 (30) | 4-40 | 6-60 |
| Maximum Ram Pressure (MPa) | 0.27 (Stepless Pressure Adjustment) | 0.37 (Stepless Pressure Adjustment) | 0.58 | 0.5 | 0.52 0.6 (Hydraulic) |
0.54 0.6 (Hydraulic) |
| Main Motor Power (KW), All AC | 110 | 280 | 315 | 630 | 1,250 | 2,500 |
| Overall Dimension – L | 5,560 | 5,800 | 6,000 | 8,900 | 7,450 | 11,150 |
| Overall Dimension – W | 2,700 | 2,500 | 2,850 | 3,330 | 4,140 | 4,960 |
| Overall Dimension – H | 3,250 | 4,155 | 4,450 | 6,050 | 6,270 | 7,040 |
| Total Equipment Weight (kg) | 16,000 | 22,000 | 29,000 | 36,000 | 59,000 | 78,000 |
