| Item / Model | X(S)N-5E | X(S)N-10E | X(S)N-20E |
|---|---|---|---|
| Total Kneading Volume (L) | 18 | 32 | 55 |
| Total Mixing Volume (L) | 5 | 10 | 21 |
| Drive Motor Power (KW) | 22-45 | 55-90 | 75-132 |
| Tilting Angle (°) | 140 | 140 | 140 |
| Rotor Speed (r/min) | 6-60 | 6-60 | 4-40 |
| Ram Pressure on Rubber (MPa) | 0.1-0.6 | 0.1-0.6 | 0.1-0.6 |
| Overall Dimension (L×W×H) (mm) | 1800x1400x1800 | 2300x1800x2600 | 3900x1750x1750 |
| Total Weight (kg) | 3200 | 5600 | 9800 |
| Item / Model | X(S)N-35E | X(S)N-55E | X(S)N-85E | X(S)N-110E |
|---|---|---|---|---|
| Total Kneading Volume (L) | 105 | 150 | 255 | 300 |
| Total Mixing Volume (L) | 36 | 56 | 82 | 110 |
| Drive Motor Power (KW) | 110-185 | 200-280 | 280-315 | 450-550 |
| Tilting Angle (°) | 140 | 140 | 140 | 140 |
| Rotor Speed (r/min) | 4-40 | 4-40 | 4-40 | 4-40 |
| Ram Pressure on Rubber (MPa) | 0.1-0.6 | 0.1-0.6 | 0.1-0.6 | 0.1-0.6 |
| Overall Dimension (L×W×H) (mm) | 4100x3000x4000 | 4200x3400x4400 | 5900x2720x4760 | 7000x3200x5200 |
| Total Weight (kg) | 18200 | 19800 | 26000 | 32000 |
